224 Dimensioning AccuVision
®
AV6010 Long-Range Camera System Manual
Accu-Sort Systems, Inc. A7-AV6010_Dimensioning_R13.doc
Certified Dimensioning for Legal-for-Trade Applications
The AccuVision AV6010 Long-Range Camera System is certified to meet the
following regulatory requirements:
The NCWM (National Conference on Weights and Measures)
NTEP (National Type Evaluation Program)
Measurement Canada (MC) *
International Organization of Legal Metrology (OIML) R129,
Measurement Instrument Directive (MID), and
Western Europe Legal Metrology Cooperation (WELMEC)
Remote Display
In all legal-for-trade applications, the AV6010 certified dimensioning system
is required to have at least one remote display per site for inspection
purposes. This can either be a laptop computer or the optional Remote
Display available from Accu-Sort (Figure G-4).
The Remote Display is a 2 line by 20 character vacuum fluorescent display.
The display shows the dimensions for the most recent two boxes (with the
most recent box on the lower line). The display will show:
B L L . L W W . W H H . H i n or mm
Figure G-10: Dimensions on Remote Display
where:
B is box number (0 to 9)
L is longest horizontal dimension (length)
W is shortest horizontal dimension (width)
H is height
Dimensions are displayed in either inches or millimeters.
* Measurement Canada (MC) requires a dedicated Remote Display for every
dimensioning system on site. Most other certified dimensioning applications will
use a customer-supplied laptop computer as the remote display.
