Datalogic Accu-Sort AccuVision AV6010 User Manual

AccuVision
®
AV6010 Long-Range Camera System Manual Chapter 3 35
03-AV6010_Mechanical_Installation_R10.doc Accu-Sort Systems, Inc.
Equipment Mounting
Complete camera system equipment installation:
 Camera Module(s) (up to 6)
 Focus Mirror(s) (up to 6)
 RangeFinder Module
 Tachometer
 Power Distribution Box
 Others (Options)
NOTE: If your application uses an Accu-Sort mounting structure, the
positions of the RangeFinder, camera sleds and mirror sleds are pre-marked
to simplify installation.
Prerequisites:
 Structure installation completed
 Structure drawings (standard or custom) showing proper positioning of
equipment on the structure
 Application’s specifications
Tools Required:
 Socket Driver (1/2”) (battery powered, recommended)
 Allen Wrench (5/32”)
 Tape Measure (minimum 12 to 25-feet [3.65 to 7.62 meter])
