48 Electrical Installation AccuVision
®
AV6010 Long-Range Camera Manual
Accu-Sort Systems, Inc. 04-AV6010_Electrical_Installation_R12.doc
Installing a Single Camera System
Prerequisites:
 Complete preparations for electrical installation (see page 47)
 Cabling (supplied with equipment)
 Channel locks (for holding cables inside structure channels)
(supplied with structure)
 Single-camera system interconnect drawing 112754 in Appendix I
(or installation-specific interconnect drawing, if provided)
Tools Required:
 None (basic tools may be needed to make mechanical adjustments)
To electrically install an AV6010 single camera system:
1. Ground the mounting structure to protective earth (PE) ground.
2. Connect RangeFinder to its power supply.
3. Connect the RangeFinder power supply to its power source.
4. Connect the AV6010 Camera to its power source.
