AccuVision
®
AV6010 Long-Range Camera System Manual Appendix A 147
A1-AV6010_Specifications_R10.doc Accu-Sort Systems, Inc.
A Specifications
AV6010 Camera System Technical Specifications
Characteristic Description
Name
AccuVision
®
AV6010 Long Range Camera System
Resolution
250 DPI
Transport Speed (max.)
Belt: 620 FPM [3.2 MPS]
Size: Camera (w/Short Illum)
H 11.15” [283 mm] x W 32.75” [832 mm] x L 15.31” [389 mm]
Camera (w/Long Illum)
H 11.15” [283 mm] x W 44.75” [1137 mm] x L 15.31” [389 mm]
RangeFinder
H 5.42“ [138 mm] x W 3.25” [83 mm] x L 36.0” [915 mm]
Weight
Camera - Short Illum: 68.08 lbs [30.8 kg] Long Illum 81.79 [37.1 kg]
RangeFinder: 18.0 lbs [8.2 kg]
Enclosure
Camera: Rigid cast aluminum chassis with powder-coated aluminum access covers
RangeFinder: Powder-coated extruded aluminum
Temperature
Operating: +32° to +122° F [0° to +50° C]
Storage: -4° to +158° F [-20° to +70° C]
Relative Humidity
10% - 90% non-condensing
Illumination (Light Source)
Camera: High intensity red LEDs (635 nm)
RangeFinder: Two visible red lasers (650 nm)
Power Requirements
115/230 VAC, 50/60 Hz, 85-110%
Power Consumption
450 VA max. for standard configuration; 800 VA max. with all options
Visual Indicators (6 LEDs)
Camera: STAT, TRIG, TACH, HOST, L/C, PWR RangeFinder: 7 status LEDs
Bar Code Types
All standard 1D and 2D symbologies
Connections
Gigabit Ethernet TCP/IP (RJ45), Serial RS232/422 (9-pin ‘D’)
Distributed Computing
Module
LynxOS on main processor, Linux OS on up to 3 Com Express modules
Options
Dimensioning, Raw Image Export (RIE) for OCR,
Monitor and Keyboard with trackball
VisionCapture (Image Depot Server / IDS), FAST Monitor
Vibration Limit
Camera and RangeFinder: 2G (10-500 Hz continuous) maximum
Reliability
> 75,000 hours MTBF @ 50° C
Service Options
Installation assistance and on-site training
Warranty
1-year limited, parts and labor; available Blue Ribbon Extended Service (BRES)
Compliances
UL, cUL, CE, FCC (Class A), IEC-60825-1, 21CFR1040
Certified Dimensioning Approvals: NCWM/NTEP, Measurement Canada,
OIML R129 (see Appendix G)
* Actual performance may vary with configuration and application.
