AccuVision
®
AV6010 Long-Range Camera System Manual Raw Image Export (RIE) 229
A8-AV6010_Raw_Image_Export_R10.doc Accu-Sort Systems, Inc.
H Raw Image Export (RIE)
Introducing AV6010 with Raw Image Export (RIE)
Any bar code reading application using an AV6010 Camera can also be
configured to provide raw image export (RIE) of high-resolution images at
high speeds. Typically, this is used in optical character recognition (OCR)
applications.
If your system is RIE-enabled, the camera(s) will be equipped with a DCM
that includes the optional Raw Image Export (RIE) COM-e module.
There are only a few special hardware or electrical installation requirements
for an AV6010 RIE application. The initial RIE setup is handled through the
AV6010’s web-browser user interface.
CAUTION: Because of the complexity of the AV6010 Camera System, it is
recommended that only authorized and trained service technicians perform
set-up, parameter adjustments, changes or FRU part replacement. Special
training is required for AV6010 systems equipped with RIE. Training is
available from Accu-Sort. Contact your sales representative or customer
service for additional information. Do not attempt to set-up a system for RIE
without proper training or the assistance of Accu-Sort technical support.
Prerequisites:
To utilize AV6010’s in-camera raw image export (RIE) capabilities, the
following is required:
AV6010 Camera(s) with RIE-capable DCM
(COM-e#3 populated for RIE and 1GB Copper board in PCI slot)
Review application specifications and define requirements with
an Accu-Sort Applications Engineer
The basic requirements for interfacing with AV6010 RIE includes:
RIE Destination Server (Linux-based)
(Hardware configuration is determined with the user by an Accu-Sort
application engineer based upon the application requirements.)
Dual port network card (1GB throughput per RJ45 port)
(Slower applications may only use one port)
C++ (or C) compatibility with the ASI RIE Library / Application
Programming Interface
