AV6010 Long-Range Camera Manual Chapter 4 47

04-AV6010_Electrical_Installation_R12.doc Accu-Sort Systems, Inc.

4 Electrical Installation

WARNING: Electrical installation by qualified service technicians

only! A trained technician must perform any procedures involving potential

exposure to high voltage electricity. Do not attempt to perform any electrical

installation procedures unless you are a trained technician.

IMPORTANT: The AV6010 contains electronics that may be affected by

electrostatic discharge (ESD). To prevent personal injury or damage to the

unit, please follow the safety precautions and warnings found in Chapter 2.

Failure to follow these precautions may void your warranty.

Preparing for Electrical Installation

Before performing any electrical installation, please do the following:

 Read all instructions before beginning your installation.

 Observe all electrical safety requirements. (See Chapter 2.)

 Complete mechanical installation. (See Chapter 3.)

 Review all installation-specific drawings.

 Compare any installation-specific information to the standard

Interconnection and Pinout drawings in Appendix I.

Note the differences (if any).

 Define and confirm the accuracy of your application’s requirements.

 Plan the power requirements for your application.

 Define the communications requirements for your application.

IMPORTANT: AV6010 cameras ship with all the necessary cabling

required to electrically install the system. If your system requires custom-

length cables or other special wiring, your shipment includes documentation

specific to these requirements. Customer-specific documentation provided

by Accu-Sort supersedes any contradictory content in this manual.

Before proceeding with any installation procedures, be sure to review ALL

documentation, especially any containing details specific to your installation.

Installation Sequence(s)

NOTE: Everything should be MECHANICALLY INSTALLED before

performing any ELECTRICAL INSTALLATION. See Chapter 3 for

mechanical installation details.
