A three-sided scanning array is used to read bar codes on the top and sides
of packages. When three or more cameras are used, a Power Distribution
Box (PDB) is typically designed into the system.
Figure 1-6: Scanning Tunnel – 3-Sided Application
A 5-sided or 6-sided scanning tunnel is used to read bar codes on most or all
sides of the products passing through the tunnel, including the bottom of
packages. (See Figures 1-7 and 1-8.)
