162 AV6010 User Interface AccuVision
®
AV6010 Long-Range Camera System Manual
Accu-Sort Systems, Inc. A2-AV6010_User Interface_R10.doc
Setup > Mounting > (Camera Orientation) Descriptions
Selection Definition
Camera Pitch Angle – This is the angle of the camera mirror in
relation to the product to be scanned.
Mounting
Angles
Camera Yaw (0 to 180) – This is the position of the camera in
relations to the direction of product flow. The camera yaw
affects the decoding of certain types of bar codes. It also
affects the orientation of the image in the image viewer.
Dist. From Trigger (X) –This is the distance from the
RangeFinder or light curtain to the AV6010 read area.
Camera Offset (Y) – This option aligns the package to the
software cropping area. Used with image cropping.
(See Communications > (Camera) > Image Network.)
Mounting
Position
Mounting Height (Z) – Defines the farthest distance a package
will be seen by the AV6010.
Front – Extends the trigger signal on the front of the box
Tracking Box
Extensions
Back – Extends the trigger signal on the Back of the box
A camera mounting screen is available for every camera connected to the
system (e.g., front, top, back, sides, and bottom) as shown on the System
Configuration screen. These parameters must be set individually for each
camera in the system.
