Options > Dimensioning Descriptions
Selection Definition
Dimensioning Options
Dimensioning Enabled (checkbox) – Dimensioning is enabled when box is checked.
CERT Off – The certification mode of the system is turned off. Changes
can only be made on this screen when the CERT Off is selected.
CERT On - English – The certification mode is enabled and reports
dimensioning data in inches.
CERT On - Metric – The certification mode is enabled and reports
dimensioning data in millimeters (12D).
Certification Mode
(drop-down list)
CERT On - OIML Metric – The certification mode is enabled and reports
dimensioning data in millimeters (10D).
Package Height Options
Variation
Threshold
Set this to be double the height accuracy.
Example: An 0.1 accuracy should have a variation threshold of 0.2.
Accuracy
(drop-down list)
Set for 0.1, 0.2 or 0.5 (5, 10, 20 mm) based on the calibrated accuracy
of the system’s RangeFinder.
Package Length/Width Options
Confidence
Threshold
Enter as a percentage (0-100%)
Accuracy
(drop-down list)
Set for 0.1, 0.2 or 0.5 (5, 10, 20 mm)
Certified Package Size Options
Length – Can be set to the certified minimum or greater.
Width
Minimum
Package Size
Height
Length (up to 72”)
Width (up to 36”)
Maximum
Package Size
Height (up to 36”)
Ranger Left
Extend Offset
Ranger Right
Extend Offset
Advanced Options
Direction of Travel Length
Determined by
Longest Side
See Chapter 5 for details on Dimensioning Setup and Calibration.
Additional reference information on dimensioning is provided in Appendix G.
