186 AV6010 User Interface AccuVision
®
AV6010 Long-Range Camera System Manual
Accu-Sort Systems, Inc. A2-AV6010_User Interface_R10.doc
Diagnostics > Tools Descriptions
Selection Definition
View/Load Parameter File
View Parameter
File
Use to view and/or save the camera system’s XML file. In a
multiple-camera system, this XML file contains the parameters
for all cameras in the system.
Load Parameter
File
Use to browse for an XML parameters file saved on your
computer and load it to the AV6010 camera system. In a multi-
camera system, the XML file contains all the parameters for
the entire system.
Downloads (on Utilities and Documentation)
InstallWizard.zip Use to download the AV6010 Install Wizard used to calibrate /
recalibrate the AV6010 RangeFinder and camera(s).
CameraScanLine
Target.pdf
Use to download the Camera Scan Line Target PDF. This
target is used with the Install Wizard to determine the distance
from the trigger source to camera scan line.
Static
FocusTarget.pdf
Use to download the Static Focus Target PDF. This target is
used with the Install Wizard during calibration / recalibration.
ImageViewer.zip Use to download the Image Wizard tool.
Dynamic
FocusTarget.pdf
Use to download the Dynamic Focus Target PDF. This target
is used with the Image Viewer during calibration / recalibration.
DiagTools.zip Use to download the Diagnostics Tools (i.e., Camera Image
Viewer, Codeword Viewer and Ranger OScope)
<Need to add the Dimensioning barcodes PDF for ASIDIM and
ASICAL.>
Set Passwords
Setup Password Assign a new password for users that will have access to the
setup features of the system.
Monitor
Password
Assign a new password for users that will have access to the
monitoring capabilities of the system.
Set Passwords Click to set the new Setup and Monitor passwords.
Update Software
Load Image
Load Patch
