200 AV6010 and FAST Monitor AccuVision
®
AV6010 Long-Range Camera System Manual
Accu-Sort Systems, Inc. A4-AV6010_and_FAST_Monitor_R10.doc
NOTE: Jot down the camera’s IP address as shown in the Static Network
Settings section of the Network window. This IP is required when setting up
the connection to the AV6010 camera in the FAST Monitor User Interface.
4. Add the FAST Monitor server to the next available Host Port in the Host
Network Connection section of the Network window.
5. Select Fast Monitor from the Host Port(n) drop-down list.
6. Type the IP address of the FAST Monitor server in the IP input field.
NOTE: The default IP for the FAST Monitor server is 192.168.250.1.
If this IP does not work, contact Accu-Sort support at 1-800-BAR-CODE.
7. Type 9899 in the Port # input field.
8. Click Update.
For additional information on setting up the FAST Monitor Server to connect
to an AV6010 Tunnel, see the FAST Monitor User Guide.
