226 Dimensioning AccuVision
®
AV6010 Long-Range Camera System Manual
Accu-Sort Systems, Inc. A7-AV6010_Dimensioning_R13.doc
Figure G-11: Location of Specification Label for
Approved AV6010 Dimensioning System (NTEP/MC/OIML)
Top-Read Camera
is sealed here
(See Figure G-1)
Label applied to underside of
the Top-Read Camera’s DCM
(See Figure G-12 and G-13)
To Next Page
