AV6010 Long-Range Camera System Manual Chapter 5 97
05-AV6010_Setup_R10.doc Accu-Sort Systems, Inc.
RangeFinder’s scan line on conveyor,
edges of usable belt shown
Close-up of the RangeFinder’s
scan line pattern (code words)
RangeFinder Scan Line
Measuring from edge of conveyor
to the alignment dot
Close-up of measuring
to the alignment dot
Measuring to determine the Region of Interest
Left side
of conveyor
Right side
of conveyor
Direction of
Travel
