190 AV500/AV900 2D CAMERA
SEQUENTIAL
When sequential is selected it allows for the AV500/AV900 to read bar codes in two separate
zones without the need of a photo sensor. the AV500/AV900 will set two separate focus zones
and control the frames it keeps the focus for each zone
Near Focus Distance
Enter the Near Zone Focus Distance is the distance from the back of the scanner to the Mid
range of the near read zone.
Near Number of Frames
Enter the Near Number of Frames determines the number of frames the AV500/AV900 will
remain in the near zone until it changes its focus to the far zone.
Far Focus Distance
Enter the Far Zone Focus Distance is the distance from the back of the scanner to the Mid
range of the far read zone.
Far Number of Frames
Enter the Far Number of Frames determines the number of frames the AV500/AV900 will
remain in the far zone until it changes its focus to the near zone.
Gain
Gain Mode
Select Profile or Fixed from the drop-down list.
When profile is selected the AV500/AV900 will adjust the image Sensitivity according to the
identified distance from the camera. The closer the package is to the AV500/AV900 the lower
the sensitivity. The farther the distance, the greater the Sensitivity adjustment.
