degdrive DGI900 - Page 116

116
PF.12 AO1 target
voltage 1
0.500V～4.000V 0.001V 2.000V ○
PF.13 AO1 measured
voltage 1
0.500V～4.000V 0.001V 2.000V ○
PF.14 AO1 target
voltage 2
6.000V～9.999V 0.001V 8.000V ○
PF.15 AO1 measured
voltage 2
6.000V～9.999V 0.001V 8.000V ○
PF.16 AO2 target
voltage 1
0.500V～4.000V 0.001V 2.000V ○
PF.17 AO2 measured
voltage 1
0.500V～4.000V 0.001V 2.000V ○
PF.18 AO2 target
voltage 2
6.000V～9.999V 0.001V 8.000V ○
PF.19 AO2 measured
voltage 2
6.000V～9.999V 0.001V 8.000V ○
PF.20 AI curve 4
minimum input
-10.00V～PF.22 0.01V 0.00V ○
PF.21 Corresponding
setting of AI
curve 4 minimum
input
-100.0%～+100.0% 0.001 0.0% ○
PF.22 AI curve 4
inflexion 1 input
PF.20～PF.22 0.01V 3.00V ○
PF.23 Corresponding
setting of AI
curve 4 inflexion
-100.0%～+100.0% 0.001 30.0% ○
