P8.06 to P8.10 to the parameter setting for the common standard
Y series asynchronous motor.
P8.27
Encoder pulses per
revolution
Setting Range: 1～65535 1024
This parameter is used to set the pulses per revolution (PPR) of
ABZ or UVW incremental encoder. In CLVC mode, the motor
cannot run properly if this parameter is set incorrectly.
P8.28
Encoder type
Setting Range: 0～4 0
0：ABZ incremental encoder；1：UVW incremental encoder；2：Resolver；3：SIN/COS
encoder; 4：Wire-saving UVW encoder.
The DGI900 supports multiple types of encoder. Different PG cards are required for different
types of encoder. Select the appropriate PG card for the encoder used. Any of the five
encoder types is applicable to synchronous motor. Only ABZ incremental encoder and
resolver are applicable to asynchronous motor.
After installation of the PG card is complete, set P8.28 properly
based on the actual condition. Otherwise, the AC drive cannot run
properly.
P8.30
A/B phase sequence of ABZ
incremental encoder
Setting Range: 0～1 0
0：Forward；1：Reverse.
This parameter is valid only for ABZ incremental encoder (P8.28
= 0) and is used to set the A/B phase sequence of the ABZ
incremental encoder.
P8.34
Number of pole pairs of resolver
Setting Range: 1～65535 1
