The X terminals (CI,VI)of the DGI900 all support the corresponding setting jump function,
which fixes the X input corresponding setting at the jump point when X input corresponding
setting jumps around the jump range.
For example, AI input voltage jumps around 5.00 V and the jump range is 4.90–5.10 V. AI
minimum input 0.00 V corresponds to 0.0% and maximum input 10.00 V corresponds to
100.0%. The detected AI input corresponding setting varies between 49.0% and 51.0%.
If you set PF.36 to 50.0% and PF.37 to 1.0%, then the obtained AI input corresponding
setting is fixed to 50.0%, eliminating the fluctuation effect.
6.17 User-Defined Function Codes（Group E0）
E0.00 User-Defined Function
Code 0
Setting Range:
uP0.00～ub0.xx
P0.00
E0.01 ~ A2.30 User-Defined Function
Code 01 to 30
Setting Range:
uP0.00～ub0.xx
P0.01
E0.31 User-Defined Function
Code 31
Setting Range:
uP0.00～ub0.xx
P0.02
Group E0 is user-defined parameter group. You can select the required parameters from all
DGI900 functions codes and add them into this group, convenient for view and modification.
Group E0 provides a maximum of 32 user-defined parameters. If "uP0.00" is displayed, it
indicates that group E0 is null. After you enter user-defined function code mode, the
displayed parameters are defined by E0.00 to E0.31 and the sequence is consistent with
that in group E0.
6.18 Motor 2 to Motor 4 Parameters（Group E3、E4、E5）
Motor 2 parameters E3.00 to E3.37 in group E3 are the same with P8.00~P8.37, while
