It is the same as coast to stop described in P1.05.
9：Fault reset (RESET)
The terminal is used for fault reset function, the same as the function of RESET key on the
operation panel. Remote fault reset is implemented by this function.
10：RUN pause
The AC drive decelerates to stop, but the running parameters are all memorized, such as
PLC, swing frequency and PID parameters. After this function is disabled, the AC drive
resumes its status before stop.
11：Normally open (NO) input of external fault
If this terminal becomes ON, the AC drive reports E-13 and performs the fault protection
action. The fault signal has two input mode: normally open and normally close.
As you see in figure 6-17, X4 is normally open input, and KM is external fault relay.
12～15：Multi-reference terminal
The four multi-reference terminals have 16 state combinations, corresponding to 16
reference values, as listed in the followin
g table.
K4 K3 K2 K1 Reference Setting Corresponding
Parameter
OFF OFF OFF OFF Reference 0 Pb.00
OFF OFF OFF ON Reference 1 Pb.01
OFF OFF ON OFF Reference 2 Pb.02
OFF OFF ON ON Reference 3 Pb.03
OFF ON OFF OFF Reference 4 Pb.04
