Figure 6-2 Stop DC braking process
P1.11
Rotational speed tracking
mode
Setting Range：0～2 0
0：From frequency at stop - It is the commonly selected mode.
1：From zero frequency- It is applicable to restart after a long time of power failure.
2 ：
From the maximum frequency - It is applicable to the power-
generating load.
P1.12
Rotational speed
tracking speed
Setting Range：1～100 20
In the rotational speed tracking restart mode, select the rotational
speed tracking speed. The larger the value is, the faster the
tracking is. However, too large value may cause unreliable
tracking.
P1.13
Acceleration/
Deceleration mode
Setting Range：0、 1 0
