138
deceleration.
NOTE：
S-curve acceleration/deceleration suitable for startup/stop of elevator, conveyor, etc.
6.3 Auxiliary Functions（Group P2）
P2.00 JOG running frequency Setting Range：0.10～50.00Hz 5.00Hz
P2.01 JOG acceleration time Setting Range：0.1～60.0S 20.0S
P2.02 JOG deceleration time Setting Range：0.1～60.0S 20.0S
JOG acceleration time means the running time of AC drive from 0Hz to upper limit
frequency.
JOG deceleration time means the running time of AC drive from upper limit frequency to
0Hz.
Figure 6-5 JOG operation
P2.03
Acceleration time 2
Setting Range：0.1～6000.0 20.0
P2.04
Deceleration time 2
Setting Range：0.1～6000.0 20.0
P2.05 Acceleration time 3 Setting Range：0.1～6000.0 20.0
P2.06
Deceleration time 3
Setting Range：0.1～6000.0 20.0
