time base frequency
0 ： Maximum frequency （ P0.05 ） ； 1 ： Set frequency ； 2 ：
100.00Hz
P0.16
Auxiliary frequency source 2
selection
Setting Range：0～9 0
The same a
s P0.01(Main frequency source 1 selection)
P0.17
Range of auxiliary frequency
2 for 1 and 2 operation
Setting Range：0～1 0
0：Relative to maximum frequency；1：Relative to main frequency 1
P0.18
Range of auxiliary frequency
2 for 1 and 2 operation
Setting Range：
0%～150%
0
The parameter used for confirming the range of auxiliary frequency
Note： You can set the auxiliary frequency to be relative to either maximum frequency or
main frequency 1. If relative to main frequency 1, the setting range of the auxiliary
f
requency 2 varies according to the main frequency1
P0.19
Frequency source selection
Setting Range：11～
00
00
Unit’s digit：(Frequency source selection)
0：Main frequency source 1
1：1 and 2 operation (operation relationship determined by ten’s digit)
2：Switchover between 1 and 2,
3：Switchover between 1 and "1 and 2 operation"
