Figure 6-9 Detection range of frequency reached
P2.22
Jump frequency during
acceleration /deceleration
Setting Range：
0～1
0
0：Disabled；1：Enabled
It is used to set whether the jump frequencies are valid during acceleration/deceleration.
When the jump frequencies are valid during acceleration/deceleration, and the running
frequency is within the frequency jump range, the actual running frequency will jump over
the set frequency jump amplitude (rise directly from the lowest jump frequency to the
highest jump frequency). The following figure 6-10 shows the diagram when the jump
frequencies are valid during acceleration/deceleration.
DGI900 provides two group parameters of any frequency reaching detection, setting
frequency value and frequency reaching detection range respectively, shown in the figure 6-
11.
