PE.00 Swing frequency setting mode Setting Range: 0～1 0
This parameter is used to select the base value of the swing amplitude.
0：Relative to the central frequency
It is variable swing amplitude system. The swing amplitude varies with the central frequency
(set frequency).
1：Relative to the maximum frequency（PE.04）
It is fixed swing amplitude system. The swing amplitude is fixed.
PE.01 Swing frequency amplitude Setting Range: 0.0%～100.0% 【0.0%】
PE.02 Jump frequency amplitude Setting Range: 0.0%～50.0% 【0.0%】
This parameter is used to determine the swing amplitude and jump frequency amplitude.
The swing frequency is limited by the frequency upper limit and frequency lower limit.
If relative to the central frequency (PE.00=0), the actual swing amplitude AW is the
calculation result of P0.19 (Frequency source selection) multiplied by PE.01.
If relative to the maximum frequency (PE.00=1), the actual swing amplitude AW is the
calculation result of PE.04 (Maximum frequency) multiplied by PE.01.
Jump frequency = Swing amplitude AW x PE.02 (Jump frequency amplitude).
If relative to the central frequency (PE.00=0), the jump frequency is a variable value.
If relative to the maximum frequency (PE.00=1), the jump frequency is a fixed value.
The swing frequency is limited by the frequency upper limit and
frequency lower limit.
