If an X is ON, the setting is 1. If the X is OFF, the setting is 0. The value is the equivalent
decimal number converted from the X status..
PA.21 displays the status of all output terminals when the latest fault occurs, the sequence
is BIT4-DO2, BIT3-DO1, BIT2-REL2, BIT1-REL1, BIT0-FM.
If an output terminal is ON, the setting is 1. If the output terminal
is OFF, the setting is 0. The value is the equivalent decimal
number converted from the X statuses.
PA.25~ PA.32 2
nd
fault information Setting Range：
same as PA.17 to PA.24
0
PA.25 to PA.32 are the information of 2nd fault，refer to PA.17 to
PA.24
PA.33~ PA.40 1
st
fault information Setting Range：
same as PA.17 to PA.24
0
PA.33 to PA.40 are the information of 3rd fault，refer to PA.17 to
PA.24
PA.43 Fault protection
action selection 1
Setting Range：
00000~22222
00000
PA.44 Fault protection
action selection 2
Setting Range：
00000~22222
00000
PA.45 Fault protection
action selection 3
Setting Range：
00000~22222
00000
PA.46 Fault protection Setting Range： 00000
