It is used to determine whether to perform output phase loss protection.
0：Disabled; 1：Enabled
PA.14 1st fault type Setting Range：0~99 1
PA.15 2nd fault type Setting Range：0~99 1
PA.16 3rd (latest) fault type Setting Range：0~99 1
It is used to record the types of the most recent three faults of the
AC drive. 0 indicates no fault. For possible causes and solution of
each fault, refer to Chapter 7.
PA.17 Frequency upon 3rd fault It displays the frequency when
the latest fault occurs.
0.00Hz
PA.18 Current upon 3rd fault It displays the current when
the latest fault occurs.
0.00A
PA.19 Bus voltage upon 3rd fault It displays the bus voltage
when the latest fault occurs
0.00v
PA.20 X terminals status upon 3rd fault Setting Range：0~1111111111 0
PA.21 Output terminal status
upon 3rd fault
Setting Range：0~11111 0
PA.23 Power-on time upon 3rd
fault
Setting Range：0~65535h 0
PA.24 Running time upon 3rd
fault
Setting Range：0~65535h 0
PA.20 displays the status of all X terminals when the latest fault occurs, the sequence is
BIT9~ BIT0 refer to X10~ X1.
