Fig. 4-10 Example of password authentication operation
E、Inquiring fault related parameter：
Fig. 4-11 Example of inquiring fault related parameter
Note:
(1) In fault code display state, press key to inquire P6 group function code parameter.
The range is from P6.01 to P6.06. After pressing key, LED first displays function code,
and1 second later it displays automatically the value of this function code parameter.
(2) When inquiring fault parameter, press key to switch back to fault
code display state.
F、Frequency setting operation by control panel
▲
▲、▼keys
Suppose it is in stopping state and P0.01=1, the operation is as follow.
(1) Frequency integral adjustment.
(2) As press key and hold it, LED begins to increase from unit’s digit to ten’s digit, and
then to hundred’s digit. If release key and then press key again, LED will
2.3.0.5 2.0.0.52.3.4.5-P0- 2.3.0.5
