Fig.3-7 CN2 terminal order

(3) Function of CN 2 terminal shown as T able 3-4

Table 3-4 CN

2 terminal function

Sort

Terminal

Name Function Specification

Commu

nication

485+ RS485

interface

RS485 differential signal

positive terminal

Twisted or shielded wire

needed

485- RS485 differential signal

negative terminal

Digital output

DO1-

CME

Open collector

output

Optical coupling isolation, dual

polarity open

collector output

Note: CME and COM are

internally insulated, but they are

shorted by jumper JP1 on

control board. DO1 is driven by

+24 V by default. If you

want to drive DO1 by external

power supply, remove the JP1

Couple output

Output voltage range:

0–24 V

Output current range: 0–

50 mA

Refer to P4.0 2
