degdrive DGI900 - Page 36

36
Pulse output
FM-
COM
High speed
pulse output
collector
The programmable multi
function terminal defined by
P4.06 (FM input mode
selection), As open-collector
output, its specification is the
same as that of DO1.
( Common terminal：COM)
Output range defined by
P4.09, Max 100KHz
Analog input
VI Analog input VI Analog voltage input
(Common terminal：GND)
Input voltage range：
0~10V (Impedance：
47KΩ)
Resolution：1/1000
CI Analog input CI Analog voltage/ current
input，voltage/ current selected
by Jumper CI, voltage input as
default (Common terminal：
GND)
Input voltage range：
0~10V ( Impedance：
47KΩ)
Input current range：
0~20mA
(Impedance：：500Ω)
Resolution：1/1000
Analog output
AO1 Analog output
AO1
Analog voltage/ current output,
voltage/ current selected by
Jumper AO1，voltage output as
default. (Common terminal：
GND)
Current output range：
4~20mA
Voltage output range：
0~10V
