AO2 Analog output
AO2
Analog voltage/ current output,
voltage/ current selected by
Jumper AO2，voltage output as
default. (Common terminal：
GND).
Current output range：
4~20mA
Voltage output range：
0~10V
X1 Multifunctional
input terminal 1
Can be defined as
multifunctional
on-off input terminal by
programming, refer to Chapter
6.5 (P3 group) .
(Common terminal: COM)
Optical coupling
isolation, compatible
dual polarity input
Input impedance: R=2
KΩ
Max input frequency:
200Hz
Input voltage range: 9～
30V
X2 Multifunctional
input terminal 2
X3 Multifunctional
input terminal 3
X4 Multifunctional
input terminal 4
X5, besides features of XI1–XI6,
it can be used for high-speed
pulse input.
Maximum input frequency: 100
kHz
X5 Multifunctional
input terminal 5
X6 Multifunctional
input terminal 6
Power
P24 +24V common
terminal
Supply +24V power (negative
terminal: COM)
OP External power
supply
Default external power＋24V
When using external power
supply for terminal X1～X6，OP
have to connect to external
power. And remove the Jumper
of OP and +24V terminal
