Figure 6-35 Simple PLC when used as frequency source
Pb.17 Simple PLC retentive selection Setting Range: 00～11 00
Unit's digit：Retentive upon power failure；0：NO；1：YES
Ten's digit：Retentive upon stop；0：NO；1：YES
PLC retentive upon power failure indicates that the AC drive memorizes the PLC running
moment and running frequency before power failure and will continue to run from the
memorized moment after it is powered on again. If the unit's digit is set to 0, the AC drive
restarts the PLC process after it is powered on again.
PLC retentive upon stop indicates that the AC drive records the
PLC running moment and running frequency upon stop and will
continue to run from the recorded moment after it starts up again.
If the ten's digit is set to 0, the AC drive restarts the PLC process
after it starts up again.
P b.18 Running time of simple PLC
reference 0
Setting Range:
0.0s(h)～6553.5s(h)
0.0s(h)
