42 Reserved 43 PID parameter switchover
44 User-defined fault 1 45 User-defined fault 2
46 Reserved 47 Reserved
48 External STOP terminal 2 49 Deceleration DC braking
50 Clear the current running time
Description of the functions shown in table 6-1：
1～2 ： Forward/Reverse terminals
The terminal is used to control forward or reverse RUN of the AC drive.
3: Three-line control
The terminal determines three-line control of the AC drive. For details, see the description of
P3.14.
4～5: Forward/Reverse JOG
FJOG indicates forward JOG running, while RJOG indicates reverse JOG running. The JOG
frequency, acceleration time and deceleration time are described respectively in P2.00,
P2.01 and P2.02.
6～7：Terminal UP/ Terminal DOWN
If the frequency is determined by external terminals, the terminals with the two functions are
used as increment and decrement commands for frequency modification. When the
frequency source is digital setting, they are used to adjust the frequency. The change rate of
terminal UP/DOWN per second is set by P3.15.
8：Coast to stop
The AC drive blocks its output, the motor coasts to rest and is not controlled by the AC drive.
