degdrive DGI900 - Page 154

154
Value Function
Value
Function
0 No function 1 Forward RUN (FWD)
2 Reverse RUN (REV) 3 Three-line control
4 Forward JOG (FJOG) 5 Reverse JOG (RJOG)
6 Terminal UP 7 Terminal DOWN
8 Coast to stop（FRS） 9 Fault reset
10 RUN pause 11 Normally open(NO) input of external
fault
12 Mulit-reference terminal 1 13 Mulit-reference terminal 2
14 Mulit-reference terminal 3 15 Mulit-reference terminal 4
16 Terminal 1 for acceleration
/deceleration time selection
17 Terminal 2 for acceleration
/deceleration time selection
18 Frequency source switchover 19 UP/DOWN setting clear (terminal,
operation panel）
20
Command source switchover
1
21 Acceleration/Deceleration prohibited
22 PID pause 23 PLC status reset
24 Swing pause 25 Counter input DI5
26 Counter reset 27 Length count input
28 Length reset 29 Reserved
30 Reserved 31 Reserved
32
Immediate DC braking
33 Normally closed(NC)input of external
fault
34 Frequency modification
forbidden
35 Reverse PID action direction
36 External STOP terminal 1 37
Command source switchover terminal
2
38 PID integral pause 39 Switchover between main frequency
source X and preset frequency
40 Switchover between main
frequency source Y and
preset frequency
41 Reserved
