For details on the frequency sources, see the description of P0.01 (Main frequency source 1
selection). Different running command sources can be bound to the same frequency source.
If a command source has a bound frequency source, the frequency source set in P0-02,
P0.16 and P0.19 no longer takes effect when the command source is effe
ctive.
P0.25 G/P type display Setting Range：0～1 Model
dependent
This parameter is used to display the delivered model and cannot be modified.
1: Applicable to constant torque load with rated parameters specified
2: Applicable to variable torque load (fan
and pump) with rated parameters
specified
P0.26 Motor parameter group
selection
Setting Range：0～3 0
The DGI900 can drive four motors at different time. You can set the motor nameplate
parameters respectively, independent motor auto-tuning, different control modes, and
parameters related to running performance respectively for the four motors.
Motor parameter group 1 corresponds to groups P8 and P9. Motor parameter groups 2, 3
and 4 correspond to groups E3, E4 and E5 respectively.
You can select the current motor parameter group by using P0.26
or perform switchover between the motor parameter groups by
means of a X terminal. If motor parameters selected by means of
P0.26 conflict with those selected by means of X terminal, the
selection by X is preferred.
