34：Zero current state：Refer to the descriptions of P2.32 and P2.33.
35：Module temperature reached
If the heat-sink temperature of the inverter module (P7.06) reaches the set module
temperature threshold (P2.45), the terminal becomes ON.
36：Software current limit exceeded：Refer to the descriptions of P2.32 and P2.33
37：Frequency lower limit reached (having output at stop)
If the running frequency reaches the lower limit, the terminal becomes ON. In the stop state,
the signal becomes OFF.
38 ： Fault output ： If a fault occurs on the AC drive and the AC drive stop, the terminal
becomes ON.
39：Motor overheat warning
If the motor temperature (b0.34) reaches the temperature set in PA.54 (Motor overheat
warning threshold), the terminal becomes ON.
40 ： Current running time reached ： If the current running time of AC drive exceeds the
value of P2.51, the terminal becomes ON.
41：Fault output
When the AC drive stops due to a fault, the terminal becomes ON.
Mark：No output when under-voltage
P4.06
FMP function selection
Setting Range：0～16 0
P4.07
AO1 function selection
Setting Range：0～16 0
P4.08
AO2 function selection
Setting Range：0～16 1
