1: by control panel key, with memory after power off
2: analog setting via VI terminal
3: analog setting via CI terminal
4: Pulse terminal setting (PULSE)
5: combination setting
6: Simple PLC function
7: PID setting
8: serial port setting (remote control)
4.1.3 Inverter Running States
When inverter power on, there are two states which are Standby and running state.
Standby state: When power switch on, inverter will be in standby state before receiving
control command. Or receiving Stop command during inverter running, inverter will stop and
standby.
Running state: After running control command is received, the inverter enters running state
The Running Modes of Inverter
There are five running modes according to priority which are JOG running, close loop
running, PLC running, multi-stage speed running and normal running as shown in Fig.4-1.
0：JOG running
In stopping state, after receiving JOG running command, the inverter will run according to
▲
▼
REV
E
