PE.03 Swing frequency cycle Setting Range: 0.0s～3000.0s 10.0s
PE.04 Triangular wave rising time
coefficient
Setting Range: 0.0%～100.0% 50.0%
PE.03 specifies the time of a complete swing frequency cycle.
PE.04 specifies the time percentage of triangular wave rising time to PE.03 (Swing
frequency cycle).
Triangular wave rising time = PE.03 (Swing frequency cycle) x PE.04 (Triangular wave rising
time coefficient, unit: s)
Triangular wave falling time = PE.03 (Swing frequency cycle) x (1
–PE.04 Triangular wave rising time coefficient, unit: s)
PE.05 Set length Setting Range: 0m～65535m 1000m
PE.06 Actual length Setting Range: 0m～65535m 0m
PE.07 Number of pulses per meter Setting Range: 0.1～6553.5 100.0
The preceding parameters are used for fixed length control.
The length information is collected by X terminals. PE.06 (Actual length) is calculated by
dividing the number of pulses collected by the X terminal by PE.07 (Number of pulses each
meter).
When the actual length PE.06 exceeds the set length in PE.05, the DO terminal allocated
with function 10 (Length reached) becomes ON.\
During the fixed length control, the length reset operation can be performed via the X
terminal allocated with function 28. For details, see the descriptions of Group P3.
