When the oscillation suppression function is enabled, the rated
motor current and no-load current must be correct. Otherwise, the
V/F oscillation suppression effect will not be satisfactory.
P5.13
Voltage source for V/F
separation
Setting Range：0~8 Model
dependent
P5.00 setting to 10 or 11：the function is valid when V/F separation.
0：Digital setting(PA.13)：The output voltage is set directly by PA.13.
1 ： VI
2 ： CI
The output voltage is set by VI terminals.
4、Pulse setting：The output voltage is set by pulses of the terminal X5.
Pulse setting specification: voltage range 9–30 V, frequency range 0–100 kHz.
5、Multi-reference
If the voltage source is multi-reference, parameters in group PF must be set to determine
the corresponding relationship between setting signal and setting voltage. 100.0% of the
multi-reference setting in group PF corresponds to the rated motor voltage.
6、Simple PLC
If the voltage source is simple PLC mode, parameters in group PF must be set to determine
the setting output voltage.
7 、 PID ：The output voltage is generated based on PID closed loop. For details, see the
description of PID in group PE.
