maximum frequency dependent
P8.05
Rated motor rotational speed
Setting Range:
1–65535 RPM
Model
dependent
Set the parameters according to the motor nameplate no matter whether V/F control or
vector control is adopted.
To achieve better V/F or vector control performance, motor auto-
tuning is required. The motor auto-tuning accuracy depends on
the correct setting of motor nameplate parameters.
P8.06
Stator resistance
Setting Range:
0.001Ω～65.535Ω
Model
dependent
P8.07
Rotor resistance
Setting Range:
0.001Ω～65.535Ω
Model
dependent
P8.08
Leakage inductive reactance
Setting Range:
0.01mH～655.35mH
Model
dependent
P8.09
Mutual inductive reactance
Setting Range:
0.01mH～655.35mH
Model
dependent
P8.10
No-load current
Setting Range:
0.01A～655.35 A
Model
dependent
The parameters in P8.06 to P8.10 are asynchronous motor parameters. These parameters
are unavailable on the motor nameplate and are obtained by means of motor auto-tuning.
Only P8.06 to P8.08 can be obtained through static motor auto-tuning. Through complete
motor auto-tuning, encoder phase sequence and current loop PI can be obtained besides
the parameters in P8.06 to P8.10.
Each time "Rated motor power" (P8.01) or "Rated motor voltage"
(P8.02) is changed; the AC drive automatically restores values of
