78
5：Curve 5（4 points，see
PF.28～PF.35）
Ten’s digit：CI curve
selection，same as VI
P3.37
Setting for AI less
than minimum
input
Unit’s digit：setting for VI
less than minimum input
0：Minimum value
1：0.0%
Ten’s digit：setting for CI
less than minimum input
111 000 ○
P3.38 X1 delay time 0.0S ～ 3600.0S 0.1S 0.0S ×
P3.39 X2 delay time 0.0S ～ 3600.0S 0.1S 0.0S ×
P3.40 X3 delay time 0.0S ～ 3600.0S 0.1S 0.0S ×
P3.41
X valid mode
selection 1
0: High level valid
1：Low level valid
Unit’s digit：X1
Ten’s digit：X2
Hundred’s digit：X3
Thousand’s digit：X4
Ten thousand’s digit：X5
11111 00000 ×
P3.42
X valid mode
selection 2
0: High level valid
1：Low level valid
Unit’s digit：X6
Ten’s digit：X7
Hundred’s digit：X8
Thousand’s digit：X9
Ten thousand’s digit：X10
11111 00000 ×
