89
P7.02 LED display
running
parameters 1
0000～FFFF
Bit00: Running frequency
1(Hz)
Bit01: Set frequency (Hz)
Bit02: Bus voltage(V)
Bit03: Output voltage(V)
Bit04: Output current(A)
Bit05: Output power(KW)
Bit06: Output torque (%)
Bit07:DI input status
Bit08:DO output status
Bit09:A/1 voltage（V)
Bit10:A/2 voltage（V)
Bit11:A/3 voltage（V)
Bit12: Count value
Bit13: Length value
Bit14: Load speed display
Bit15:PID setting
1 001F ○
P7.03 LED display
running
parameters 2
0000～FFFF
Bit00:PID feedback
Bit01:PLC stage
Bit02:Pulse setting
frequency（kHZ)
Bit03: Running frequency
2（HZ)
Bit04: Remaining running time
Bit05:A/1 voltage before
0.1 0000 ○
