Chapter 9 Ethernet Communication Module AH10/15EN
9-13
CR
Number
Value
in the
control
register
Description
#645 K100 IOA 100 (information object address) of the remote device
#646 K1
1：ON，0：OFF
#647 K0
#620 K45
Single command code
 CR#650 ~ CR#659: Setting up the data point for the database of the slave station
 Example: AH15EN-5A as a slave, when creating data M_SP IOA 100 ~ IOA 104 to the
database and corresponding to M100 ~ M104 of the CPU register, users can input the values
according to the table below and trigger to create. The same rule applies to 2
nd
~ 16
th
remote
devices. Refer to section 9.3.5 for details on type id parameters and codes.
CR
Number
Value
in the
control
register
Description
#650 K5 Add 5 data points
#651 K1 Type identification, 1: M_SP_NA_1
#652 K100 The starting position of IOA is 100.
#653 K0
#654 K1 Group mask, 1: group 1 station interrogation
#655 K0 Flags = 0
#656 K0 Default value = 0
#657 K0
#658 K100 The starting position of CPU register is M100.
#659 K1 1: trigger to create
 CR#672 ~ CR#684: Setting up the starting position of the corresponding CPU register for the
1
st
connection of the type id of the remote device. One word represents one type id.
CR
Number
Description
#672 Single-point information corresponds to the starting position of M device
#673 Double-point information corresponds to the starting position of M device
#674 Step position information corresponds to the starting position of D device
#675 Bitstring of 32 bit corresponds to the starts position of D device
#676
Measured value, normalized value corresponds to the starting position
from D500
#677 Measured value, scaled value corresponds to the starting position of D
device
#678 Measured value, short floating point value corresponds to the starting
position of D device
#679 Integrated totals corresponds to the starting position of D device
#680
Event of protection equipment corresponds to the starting position of D
device
#681 Packed start events of protection equipment corresponds to the starting
position of D device
#682
Packed output circuit information of protection equipment corresponds to
the starting position of D device
