Configuration of the module parameters:
AH06XA-5A is set to the present values of 4 channels and 8 words of input and 2 channels and
4 words of output.
AH04DA-5A is of 4 channels and 8 words for output by default and is configured with 2
parameters “Mapping to Device” (2 words of input and output respectively). 16AP occupies 1
word of input and output respectively. Every word corresponds to one D in the mapping area of
the master (That is to map to PLC)
Setting of the input and output mapping starting addresses of the module:
Set the input an output mapping starting addresses to D1010 and D2010 respectively for
AH06XA-5A, D1030 and D2030 respectively for AH04DA-5A; D1060 and D2060 respectively for
16AP.
By means of manual allocation of addresses, D2005 and D1005 are used as the control word
and status word of AHRTU-DNET-5A respectively. Hence the corresponding input mapping
addresses and the output mapping addresses for AH06XA-5A are D1010~D1017 and
D2010~D2013 respectively; for AH04DA-5A are D1030~D1031 and D2030~D2039 respectively;
for 16AP are D1060 and D2060 respectively.
Allocated manually
Input
Output
AHRTU-DNET-5A
D1005 status word
D2005 control word
AH06XA-5A
D1010~D1017
D2010~D2013
AH04DA-5A D1030~D1031 D2030~D2039
16AP
D1060
D2060
The input and output mapping addresses of AHRTU-DNET-5A are D1005~D1060 and
D2005~D2060 respectively.
11.4.3.4 Control Word and Status Word of AHRTU-DNET-5A
The input and output starting addresses in the mapping areas of AHRTU-DNET-5A are defined as
the status word and control word respectively with the detailed explanation as below.

Control word of AHRTU-DNET-5A
Bit
Status value
Definition
Bit 0~bit 2
000
Set no control of operation of AHRTU-DNET-5A
001
Set AHRTU-DNET-5A to RUN mode
010
Set AHRTU-DNET-5A to STOP mode
Other
Reserved
Bit 3
0 Reserved
1
Restart AHRTU-DNET-5A
Bit 4
0/1
Reserved
Bit 5
0/1
Reserved
Bit 6
0/1
Reserved
Bit 7 0/1 Reserved
Bit 8
0/1
Reserved
Bit 9
0/1
Reserved
Bit 10
0/1
Reserved
Bit 11
0/1
Reserved
Bit 12 0/1 Reserved
Bit 13
0/1
Reserved
Bit 14
0/1
Reserved
Bit 15
0/1
Reserved
