Serial connector
The serial connector is an M12-5 pin, A Coded connector. Pinout is as follows:
Pin DB-9 (DCE)
1 2 (RXD)
2 3 (TXD)
3 8 (CTS)
4 7 (RTS)
5 5 (GTM)
Ethernet connectors
Ethernet connector M12-4 pin, D coded
M12 Pin RJ45 Signal Notes
1 1 TX+ Twisted pair
3 2 TX-
2 3 RX+ Twisted pair
4 6 RX-
Ethernet connector M12-4 pin, D coded
M12 Pin RJ45 Signal Notes
4 6 RX- Twisted pair
6 3 RX+
5 1 TX+ Twisted pair
8 2 TX-
1 N/C
2 N/C
3 N/C
7 N/C
