The DS815 contains the following element:
n Serial connector is used for the serial link to the DS814 Link Board
(Box), DS830 or MicroAutoBox. A matching link cable is delivered
with the board.
As of November 2001 the DS815 comes with a new
serial connector. These boards have a red label or a blue
label with “Vs.2.0”. The link cables of DS815 boards
delivered before November 2001 are not compatible
with the new cables.
For the DS815 delivered as of November 2001 an
adapter cable is available:
n To adapt the DS815 to a standard patch cable with
an RJ45 connector.
n To identify the current status of the connection by
the two LEDs integrated in the shell of the RJ45
connector.
DS815 components
The adapter cable is labeled “DS815-RJ45 Vs 2.0”. It contains the
following elements:
n Status LEDs display the current status of the connection. These
LEDs can be used for troubleshooting purposes:
n A lit yellow LED indicates that the connection between the host
PC and a dSPACE box (or DS830) is ready for communication.
n A lit green LED indicates that data is being sent or received.
n Serial connector for connection of the DS815 to the host PC.
n Patch cable connector is an RJ45 connector. It is used for the link
via crossed‑over patch cable to the DS814 Link Board (Box), DS830
or MicroAutoBox.
For the connection between the DS815-RJ45 adapter
cable and the dSPACE boxes (or DS830) you must use a
crossed‑over patch cable.
DS815-RJ45 adapter cable
components
s
Accessories
t
232
s
DS1103 Hardware Installation and Configuration November 2014
