PX10 Desktop
200 mm
(7.9 in.)
200 mm
(7.9 in.)
200 mm
(7.9 in.)
Power supply
Back view
Boards
200 mm
(7.9 in.)
200 mm
(7.9 in.)
50 mm
(2.0 in.)
50 mm
(2.0 in.)
PX10 Rack
s
Accessories
t
254
s
DS1103 Hardware Installation and Configuration November 2014
