2 Turn off the host PC.
Do not switch off the expansion box while the host PC
is still running. This might lead to unpredictable errors.
3 Turn off the expansion box and all devices connected to it.
4 Disconnect the host PC, the expansion box and all devices
connected to them from the power supply.
WA R NI NG
Hazardous voltages
Risk of electric shock and/or damage to the
hardware
n Do not connect any high-voltage devices to the I/O
connectors of the hardware.
n Do not apply voltages/currents outside the specified
ranges to the connector pins.
5 Connect the devices belonging to your application to the board.
6 Reconnect the host PC, the expansion box and all external devices
to the power supply.
7 Turn on the expansion box.
To avoid unpredictable errors, you should always turn
on the expansion box before the DS830 MultiLink Panel
(if used) and the host PC.
8 If used, turn on the DS830 MultiLink Panel.
9 Turn on the host PC.
The host PC should boot as usual.
10 Turn on all external devices connected to the dSPACE system.
HowTos
• How to Connect External Devices to a Connector Panel on page 95
Related topics
s
Connecting External Devices to the dSPACE System
t
94
s
DS1103 Hardware Installation and Configuration November 2014
