Automatic corner knife station (straight pocket)

146 Service Instructions 755 A/756 A - 00.0 - 02/2019

20.4 Setting the angle of the corner knife incisions

Fig. 143: Setting the angle of the corner knife incisions (1)

Proper setting

The incisions of the corner knives should be as close to the seam as

possible, but must not cut the seam.

Fig. 144: Setting the angle of the corner knife incisions (2)

(1) - Screw (2) - Corner knife holder

①

②
