Hook
64 Service Instructions 755 A/756 A - 00.0 - 02/2019
7Hook
7.1 Changing the hook
Fig. 62: Changing the hook (1)
To change the hook:
1. Remove the throat plate.
2. Remove the hook cover with the bobbin.
3. Unscrew the fastening screws (2) of the hook.
4. Lift off and remove the hook from the hook shaft.
5. Slip a new hook (1) onto the hook shaft.
6. Push down the hook and tighten the 1
st
screw in rotational direction
on the face of hook shaft.
Next, tighten the 2
nd
screw.
7. Insert the hook cover with the bobbin.
WARNING
Risk of injury from sharp parts!
Puncture possible.
Switch off the machine before adjusting the hook
settings.
(1) - Hook (2) - Fastening screw
