Setting the trimming and clamping device for the needle threads

Service Instructions 755 A/756 A - 00.0 - 02/2019 87

12.2 Replacing knives and thread-pulling knife

Information

The knives (3) will become blunt after a certain service life. Blunt knives

need to be replaced.

Fig. 90: Replacing knives and thread-pulling knife (1)

To replace the knives and the thread-pulling knife:

1. Disconnect the cables (1).

2. Loosen the screws (2).

3. Remove the cutting device.

(1) - Cables (2) - Screws

①

②
