Endless zipper feed (optional)

Service Instructions 755 A/756 A - 00.0 - 02/2019 201

26 Endless zipper feed (optional)

26.1 Threading and activating the zipper

Information

The mounting of the zipper roll and the pulling direction of the zipper

depend on how the zipper is supposed to be sewn in.

WARNING

Risk of injury from sharp and moving parts!

Cutting and crushing possible.

NEVER reach into the area between the knives or

below the zipper cutter.
